BFN1KB System

Boingfire introduces a robust computing platform powered by the quad-core Intel Atom E3845 processor, clocked at 1.9GHz. This powerhouse is coupled with DDR3L memory, expandable up to 8 GB, ensuring fluid multitasking.

Dive into diverse storage options, including onboard eMMC4.5, an mSATA slot, and a SATA2 port with 3.0Gbps speed.

  • Intel E3845 Processor – AES-NI
  • 2 Giga bit Ports, 1 x Console Cable (RJ45)
  • Based on BFN1 Fan-less Board
  • Complete Customization Available
  • Low cost with High performance.

Designed to withstand varying environments, this unit thrives in a wide range of humidity and temperature settings. Power is efficiently managed through a 12v 2A adapter and a similar input power rating. Safety is prioritized with a watchdog feature, adjustable timeouts, and easily accessible reset options.

The icing on the cake is its fanless design, promising silent operations, coupled with additional features like an RJ45 serial port and an internal SATAII connector. Experience computing redefined with Boingfire.

Datasheet     User Guide

SKU: BFN1KB Category:

Delve into a world of unmatched performance with the Boingfire BFN1KB. Designed for those who seek reliability and efficiency, this system comes packed with features to supercharge your tasks. Equip yourself with the Boingfire BFN1KB, a fusion of state-of-the-art technology and ease of use. Whether for work or play, this system promises robust performance tailored to your needs.


Processor (CPU) Intel Atom E3845 2M Cache (AES-NI)
Core 4 (Quad Core)
CPU Frequency 1.9GHz
Storage 1 x eMMC4.5, 1 x SATA2, 1 x mSATA
Display Port N/A
Resolution N/A
Ethernet Ports 2 x RJ45 Gigabit
Ethernet Controller Intel i211AT
Watchdog Programable 1~255 Sec, 1~255 Mins. Disable
Power Button 1 x Front Pinhole, 1 x Rear Button
Reset Button 1 x Front Pinhole, 1 x Rear Button
Cooling Fan Fan-less
Serial Port 1 x RJ45 External, 2 x TTL
Power 12V ±10% only
Typical Power 0.5A @ 12V (5.28W)
Max. Power 5A @ 12V (60W)
GPIO 8-bit GPIOs
USB 1 x USB3.0, 3 x USB2.0
Mini PCIe Slot 1 x Mini-PCIE for LTE
Operating Humidity 10 – 95% RH
Storage Humidity 5 – 95% RH
Operating Temperature 0°C to 60°C
Storage Temperature -40°C to + 85 °C
Dimension 6×7.5×1.5 Inc (LxWxH)
Weight 2.3 Lbs (Approx.)
